Specifications:
Rated Voltage:AC100V~240V 50-60HZ
Rated Power: 450W
LED Qty: 36x15W High power RGBW LEDs
LED Drive Current: 1A
Beam Angle: 10°(25°,40°optional)
IP Class: IP65
DMX Mode: 2/3/4/13/16/29CH
Packing Size:585x220x425 mm
Net weight: 13.2Kg
Gross weight:15.5Kg
Product features
Dmx input:3 pin electronic J3F2C-W
Dmx output:3 pin electronic K3F2C-W
Power connection:electronic powerCON in(SAC3MPX)/ powerCON
out(SAC3FPX)
3 kinds of control model: DMX512,WDMX,Master/slave
2.4G Wireless DMX control
Setting and Addressing:RDM
DMX function:Dimmer,Strobe,RGBW,Macro color,Color jump,Color
fade,Rainbow,Auto Program choice,Auto speed,Curve dimmer
select,Function setting
Stand-alone mode: Color step,Color shade,Auto,Slave,Macro color,Static
color setting, Rainbow,Auto program choice
Housing color:Black
2.4inch TFT color display screen
Refresh rate:3000Hz
Operation temperature:-20°C ~+40°C.
6 Kinds of DMX modes:2/3/4/13/16/29CH
Dimmer mode: 2 kinds
4 kinds of curve dimmer:Linear Dimmer,Square Dimmer,I. Square Dimmer,S-Curve
Dimmer
Display board can be 180°in turn,it can be fitted in different setting
Strobe effect:Plus Random,Ramp up Random,Ramp down Random
Random strobe,Strobe Break Effect,5s......1s,Strobe 0-20Hz
Perfect mixing color and rainbow effect
Cooling system:fan cooling(Auto&high-speed)
Certficate:CE,ROHS
Stage lighting, Theater lighting, dj lights DMX Control, beam, stage equipment for show event, stage event, party, Lighting rental, music wedding event, bar, outdoor project, park, brige, hotel, buidling and so on.
