Specification

Details

Power Consumption

1400W

Light Sources

392pcs 2835 LEDs (1.56W white); 784pcs 5050 LEDs (1W RGB 3-in-1)

Pixel Matrix

White: 2×14 Groups; Color: 2×7 Groups

Lumen Full Output

R: 5480Lm; G: 11760Lm; B: 1560Lm; W: 45000Lm; Total: 63880Lm

CRI

Ra≥90

Light Source Life

20000 hours

Beam Angle

110°

Dimmer

0-100% linear dimmer

Control DMX Channel

8/11/13/24/30/74/97CH

Control Modes

DMX512, Auto, Master-Slave, Music

Display

Illuminated graphic LCD

Protocol

Art-Net, DMX-512, RDM

RDM

Bidirectional communication

Cooling

Temperature controlled, overheating protection

Construction Display

LCD Display

DMX In/Out Socket

3-pin XLR waterproof in/out

Power Socket

Waterproof powercon in/out

Protection Rating

IP65

Size - Packing Size

404×202×350MM
