Specifications:
•With same Channel as Martin Atomic 30000 Strobe
•Light source: 228x3W white LEDs (Strobe ) 64x 0.6w RGB LEDs (backlight) array
•Minimum LED lifetime: 50 000 hours
•Resolution:8 bits per color plus8-bit dimming
•Control systems: DMX
•DMX channels: 3/4/14 Channels
•Setting:Control panel with backlit monochrome display
•N.G: 7kgs /pcs
•Packing Size: 50x 24x 34cm (1pcs /carton)
•52x50x39cm (2pcs/carton)
Effect:
•The fixture has two LED arrays:
• The Beam is a high-intensity array that gives powerful strobe and blinder effects
• The Aura gives RGB effects that light up the front of the fixture to complement or contrast with the output
from the Beam.
•Strobe effects
•The 3000 LED offers strobe effects from the Beam with variable flash rate, flash duration and
•intensity. It also offers the following pre-programmed effects:
• Ramp up/down intensity modulation effects
• Random flashes
• Lightning – simulates the instantly recognizable ‘dirty’ flash of a lightning strike
• Spikes – low-intensity light output with high-intensity flashes
Blinder effects
•To obtain a continuous blinder effect, set flash duration to a long value and flash rate to a high frequency
•value so that flashes ‘overlap’ and merge into continuous light output
Aura RGB Color
•Extended DMX mode gives control of the Aura. You can set Aura color with independent RGB control and
•you can also control overall Aura intensity.
•The four different dimming curve options available in the fixture’s control menus apply to both the Beam and
•the Aura dimming curves
