1. Voltage: AC90V-235V 50-60Hz
2. Voltage driving power supply: 600W
3. Light source system: 380 (Philips)
4. Color temperature; 7900±500K
5. Color system: Color disk: 14+ colorful rainbow effect + atomization function
6. Pattern system: Pattern disk: 17 fixed patterns + 1 white light
7. Focusing system: Electronic focusing
8. Atomization; With atomization function, it can achieve soft light effect
9. Prism; 8+16 prisms, double prisms rotate, speed adjustable.
10. Motor: XY axis uses three-phase motor, which makes the speed of the lamp highly stable and the positioning angle accurate!
11. Dimming curve: 0%-100% linear dimming, smooth and flicker-free
12. Beam angle: 0-2°
13. Dual channels: 16 channels or 20 channels
14. Lens diameter: 180mm
15. Waterproof grade: IP66
16. Control mode 1: DMX 512
17. Display screen: LCD display screen, adapt to different installation positions, can rotate 180°
18: Horizontal and vertical: high-precision three-phase motor, accurate positioning, smooth operation, automatic positioning correction
19: Horizontal: 540° rotation, resolution 8/16Bit, with fine adjustment
20:. Vertical: 270° rotation, resolution 8/16Bit, with fine adjustment.
21: Shell, all die-cast aluminum.
22: Lamp body size 705*375*300cm
23: Net weight, 27KG
